− 38 −

ENGLISH GERMAN FRENCH ITALIAN SPANISH

Alignment mark

：

If the speaker angle is 0°

Alignment mark：

−30°

−15°

Installing on a ceiling (installation example)

Speaker arm : Standard

Fixing holes

：

Side with mark

（

Mark

：

）

０°



Standard speaker arm type

Alignment mark

：

If the speaker angle is

15°

Speaker arm : Standard

If the speaker angle is

30°

Speaker arm : Standard

Fine adjustment range

：−

15°

～

10°

(

󰜏

Refer to P.32.

)

Fine adjustment range：−30° ～−5°

(

󰜏

Refer to P.32.

)

Fine adjustment range：−45° ～−20°

(

󰜏

Refer to P.32.

)



 Select an installation method for the speaker arm in

accordance with the speaker installation angle that will

be used at the installation location.



 Install the speaker on the ceiling.

󰝟

Speaker

Speaker base

Speaker arm

Fixing holes

：

Side with mark

（

Mark

：

）

Fixing holes

：

Side with mark

（

Mark

：

）

･ The installation angle can be varied within a wide

range by means of the direction of the speaker arm

and the fixing holes used.

･ For examples of the speaker angles, refer to the

installation examples on pages 38 and 39.

･

The position of the fixing hole (mark) is important

when assembling the speaker and the speaker arm.

For details, refer to “Assembling the speaker” on P.46.

Tip

For details on the installation procedure, refer to P.41 -

47.

Tip

Fixing holes
