JAPANESE

ENGLISH GERMAN FRENCH ITALIAN SPANISH

Installation on a floor or shelf

･ Adjust the speaker angle. ➡Refer to P.22.

･ Example of installation to a ceiling or wall. ➡ Refer to P.25.

･ Install the speaker to the ceiling or wall. ➡Refer to P.26 - 30.

･ Adjust the speaker angle. ➡Refer to P.22.

Speaker installation exampleSpeaker installation example

Ceiling installation

Wall mounting

･ Example of installation to a ceiling or wall. ➡ Refer to P.25.

･ Install the speaker to the ceiling or wall. ➡Refer to P.26 - 30.

･ Adjust the speaker angle. ➡Refer to P.22.
